Turbo Segment Diamond Saw Blade with Flange&Silent Holes (SED-DSB-TSF)

Quantity:



Inquire Add to Basket

Blade Type:
Continuous Boundary
Manufacturing Process:
Sintered
Application:
Stone
Size:
230mm
Feature:
with Flange and Silent Holes
Segment:
Continuous Turbo Segment
Model NO.:
SED-DSB-TSF
Manufacturing Arts:
Sintered
Usage:
Stone Cutting
Min Qty:
100PCS
Transport Package:
Paper Box, Carton
Specification:
MPA, CE, ISO9001, SGS
Trademark:
EASYDRILL
Origin:
China
HS Code:
82023900
Production Capacity:
50, 000PCS/Month
Customization:
Available | Customized Request

Product Description

Product Description

small teeth turbo Diamond Saw Blade with flange and silent holes

It is widely used for cutting and nondestructive grooving on marble, granite, ceramic tile, concrete, decorative material, used on manual cutting machine.
small teeth can give Sharp cutting, wear-resistant.
Auxiliary with angle grinder, multi-cutter machines.
silent holes provide Fast cutting speed and small cutting gap.Higher cutting efficiency 20-30% than normal blades and without chipping.
Q&A
1.What are your main products?

Answer: We manufacture and supply Diamond Blades,TCT blades,HSS saw blades,drill bits for concrete,masonry,wood,metal ,glass&ceramic etc, chisels, hole saws,diamond core drill bits,grinding wheels,woodworking tools,hand tools,hardware and other power tool accessories.
2.How to order goods?
Answer: The way to process goods order is: Please offer us the inquire information including Product name or Description with Item No, Sizes,Purchase quantity,package way. Photo attached is better.We will offer your Quotation Sheet or Proforma Invoice within 24hours after receiving your order information. Then your comments on prices or payment terms,shipment terms are welcomed. Other details will be discussed accordingly.
3.Delivery time?
Answer: 20-35 days after receiving down payment in normal season. It will be changed depending payment,transportation,holiday,stock etc.
4.Would you offer free samples?
Answer: we would like to build mutual benefit long term business relationship with our clients. Normally we could offer a few pcs samples for low unit price under USD5.0. those samples can be sent free of charge. But customers just need to afford a little shipping charge, or you can provide your DHL,FEDEX,UPS courier account number to us with freight colletion.

Out Diameter(mm)	Inner Hole(mm)	Segment Thickness(mm)	Segment
Out Diameter(mm)	Inner Hole(mm)	Segment Thickness(mm)	Height(mm)
105	22.23/20	1.7/2.0	7/10
110	22.23/20	1.7/2.0	7/10
115	25.4/22.23/20	1.7/2.0	7/10
125	25.4/22.23/20	1.7/2.0	7/10
150	25.4/22.23/20	1.9/2.2	7/10
180	25.4/22.23/20	2.2/2.4	7/10
200	25.4/22.23/20	2.2/2.4	7/10
230	25.4/22.23/20	2.4/2.5	7/10
300	20/22.23/25.4/50	3.2	8
350	22.23/25.4/50	3.4	8
400	22.23/25.4/50	3.6	8
300	20/22.23/25.4/50	3.2	10
350	22.23/25.4/50	3.4	10
400	22.23/25.4/50	3.6	10
300	20/22.23/25.4/50	3.2	12
350	22.23/25.4/50	3.4	12
400	22.23/25.4/50	3.6	12
